Model	EV203	EV206	EV210	EV220
Vibration Generator	VG300/40	VG300/50	VG1000/50	VG2000/50
Frequency(Hz)	2-2500	2-3000	2-3000	2-2500
Max Exiting Force(kg.f)	300	600	1000	2000
Max. Displacement (mmp-p)	38	50	50	50
Max. Acceleration(g)	100	100	100	100
Max. Velocity(cm/s)	120	200	200	200
Payload(kg)	120	200	300	400
Armature Mass(kg)	3	6	10	20
Armature Diameter(mm)	φ150	φ200	φ240	φ320
Cooling Method	Forced Air Cooling
Vibration Generator Weight(kg)	460	920	1100	1600
Vibration Generator Dimension LWH(MM)	750555670	800600710	845685840	12008701100
Power Amplifier	Amp3k	Amp6k	Amp12k	Amp22k
Cooling Method	Forced Air Cooling
Power Amplifier Weight(kg)	250	320	350	500
Power Amplifier Dimension LWH(MM)	8005501250	8005501250	8005501520	8005501520
Utility Requirements	3-phase AC380V ±10% 50Hz
Aggregate Capacity(KW)	9	20	25	35

Our Services:

Pre-sales service

Technical Advisory: Testing method, laboratory planning and advice

Equipment Selection: Type-selecting scheme,FAQ

Product testing scheme

Selling service

Customer Communication,progress communication

Before installation, we will provide guidance of preparation , equipment debugging, equipment commissioning

Cooperate with measuring if need the third party verification

After-sale service

Quality assurance period for one year,lifelong maintenance.

Technical guidance

Feedback within 2 hours after get the call.

Accept OEM, Design service,Buyer label

Features:

Double magnetic circuit structure to ensure high magnetic field intensity & reduce flux leakage; Special degaussing structure can reduce flux leakage to below 1 mt
U-type spring ,rollers and linear bearing for strong resistance of deflecting load
Air spring are used for vibration isolation; Vibration system work steadily even with heavy load; no need special foundation
Protection devices are provided for over-thermal, over-load, over-current, over-voltage, and over-displacement of the vibration tester; Electrical network protection devices for over-voltage, under-voltage, lacking phase; Drive power , current-limiting , soft-start, over-temperature, short-current,module fault protecting
Able to complete sine ,random , impact environmental tests
This system requires voltage fluctuation, ≤±10%
This system requires Grounding resistance, ≤4Ω
High reliability, especially suitable for long-time operation

Working Principle:
